Main Performance and Features:

1.High Efficiency: The rapid traverse speed of all three axes has been increased by 50%, and the tool change time of the direct-drive spindle has been significantly improved, providing users with high-efficiency machining performance.

2.High Rigidity: The main components are all made of cast iron, ensuring that cutting forces and the machine's own weight are effectively absorbed, guaranteeing high precision machining.

3.High-Performance Spindle: Equipped with high-performance precision spindle bearings, capable of reaching speeds up to 12000rpm, coupled with a spindle oil cooling system to effectively control spindle temperature rise.

4.Tool Changer: Equipped with a 24-tool robotic tool changer, featuring quick and reliable arm exchanges, stable performance, and reduced tool change time, ensuring efficient and high-quality machining.

5.Linear Axis Drive Structure: Adopts a one-end fixed, one-end supported drive structure, combined with a pre-tensioned ball screw structure, ensuring efficient and accurate drive system operation.

6.Spindle Drive Structure: The spindle and motor are directly connected using a high-speed coupling, minimizing mechanical efficiency losses during transmission.

7.Three-Axis Linear Guide: Smooth operation, with the option of selecting roller guides.

8.Large Diameter C3-Class Ball Screws: Equipped with a pre-tension structure to eliminate thermal expansion, ball screw bearings utilize contact-sealed bearings for reliable operation.

9.Chip Disposal System: Offers an economical and practical spiral chip conveyor, as well as a smooth and reliable chain chip conveyor, providing efficient solutions for various chip types.

10.Cooling System: Large-capacity water tank, high-flow spindle head coolant system, effectively reducing temperature rise during cutting for both spindle and workpiece, and can be equipped with a high-flow flushing system to effectively remove chips.

11.Centralized Lubrication System: Efficient centralized lubrication system with reasonable oiling intervals to ensure proper lubrication of moving parts and extend service life.

12.Simple Oil-Water Separator: Using the principle of gravity settling based on the density difference between water and oil to remove oil from the cutting fluid, ensuring the circulation of the cutting fluid.

13.Optional Automatic Door: Accurate and efficient operation, providing the conditions for users to achieve automated production lines.
